High-Performance Motion Activated Solar Bollard Light for Pathways

High-Performance Motion Activated Solar Bollard Light for Pathways

– Total Height:  4000 mm

– Pole Material:  Aluminium 6063-T6

– Surface Finish:  Outdoor metal powder coating

– Pole Diameter:  Ø165 mm

– LED Power:  20 W

– Luminous Efficacy:  120 lm/W

more about usGet a free quote

Morelux is professional manufacturer of aluminum solar bollard poles for pedestrian pathways, commercial landscapes and public zones. This ESCH series bollard pole can be supplied as bare pole only, or fully‑assembled unit with optional Flexible HJT vertical solar module, motion‑sensor LED light and lithium battery. Zero‑grid solution removes expensive trenching and cabling work for municipal & landscape projects.

Key Advantages of ESCH Solar Bollard Pole

  • 6063‑T6 high‑strength aluminum bollard pole, outdoor powder‑coated anti‑corrosion finish
  • Designed for Flexible HJT vertical solar module mounting, multi‑angle sunlight harvesting
  • Compatible with motion‑activated sensor LED bollard light kit (optional assembly)
  • Smart dim‑to‑low power mode to extend battery runtime for cloudy successive days
  • IP65 protection rating for full assembled light‑solar system, dust & rain resistant
  • Customizable dimension, diameter, RAL powder‑coating color and base flange size
  • Bare pole available: match your own solar panel, LED lamp and battery components
  • Perfect for high‑traffic pedestrian pathways, park walkways, residential & commercial landscape

Bollard Pole & Optional Kit Specifications

Item Parameter
Standard Total Height 4000 mm
Pole Material Aluminium 6063‑T6
Surface Finish Outdoor metal powder coating
Pole Diameter Ø165 mm
Optional LED Kit Power 20 W (Lumileds 3030 LED chips)
Luminous Efficacy (LED Kit) 120 lm/W, Max 1200 lm output
Color Temperature (Optional Kit) 3000K / 4000K / 5000K selectable
Optional Solar Module Flexible HJT 5V 58W vertical solar module
System Protection (Full‑kit) IP65
Accessories Motion‑activated sensor, lithium battery, controller (optional)

Motion‑Sensor Lighting & Vertical HJT Solar Package (Optional)

This aluminum bollard pole is engineered to mount Flexible HJT vertical solar module on shaft surface. Vertical solar design captures sunlight from multi‑directions and reduces dust accumulation versus traditional top‑mount horizontal panels.

The matching motion‑activated LED bollard light works intelligently: trigger full‑power brightness once motion detected for pedestrian safety; auto dim in idle hours to preserve lithium battery power, supporting multi‑day operation on cloudy weather.

Note: Solar module, motion‑sensor lamp and battery are optional assembly parts. You are welcome to purchase bare aluminum bollard pole only and fit your own lighting components.

Durable 6063‑T6 Aluminum Bollard Construction

Extruded from 6063‑T6 high‑strength aluminum alloy, ESCH bollard pole delivers excellent structural performance for year‑round outdoor deployment. Outdoor powder‑coated surface resists UV degradation, oxidation and salt‑spray corrosion, suitable for humid zones and coastal landscape projects. When assembled with full light‑solar set, whole unit reaches IP65 rating against dust and rain splash.

Typical Application Scenarios

  • Public pedestrian pathways & park walkway lighting
  • Commercial plaza, resort and hotel outdoor landscape
  • High‑end residential community garden paths
  • Municipal green belt & scenic spot renovation projects

Custom Options For Solar Bollard Pole

  • Adjust bollard height, shaft diameter and wall thickness
  • Custom RAL powder‑coating color for pole surface
  • Custom base flange dimension matching your foundation drawing
  • Reserve internal wiring channel for your own light & solar parts
  • Logo or project marking print on pole surface

Frequently Asked Questions

Q1: Can I order bare aluminum bollard pole without solar panel and motion‑sensor lamp?

A: Yes, light pole is our core product. Solar module, motion‑activated LED light and battery are optional accessories. Many project clients order bare poles and assemble their own lighting system.

Q2: Is this bollard pole fit for coastal salt‑spray environment?

A: 6063‑T6 aluminum plus outdoor powder‑coating provides good anti‑corrosion performance for coastal areas. Enhanced surface treatment can be offered for extra‑harsh conditions.

Q3: Can you provide foundation installation drawing for bollard pole?

A: Yes, we can supply technical dimension sketch and foundation drawing upon order requirement.

Q4: What is production lead‑time for bulk bollard pole orders?

A: Sample lead‑time is short. Mass production time depends on quantity & custom specs. Our sales team will send exact schedule within 24 hours after receiving your project details.

1

Request Custom Bollard Pole Quote

Tell us your required pole size, quantity, coating color, and whether you need optional solar & motion‑light kit. We provide technical datasheet and competitive price for landscape & municipal projects.
